Eaton CN15BN2AB Contactor, NEMA OPEN 2P CONT SIZE 0 120V Coil

Product Description

The EATON CN15BN2AB is a 2 Pole contactor designed for use with CE or CN non-reversing and reversing contactors. It features interchangeable heater packs and is available in four sizes for overload protection up to 900 hp. It is suitable for switching motor loads in applications where running over current protection is either not required or is provided separately.

• Horizontal or vertical mounting on upright pane allows for application-freedom
• Screw type power terminals have captive, backed out self lifting pressure plates with screws result in reduced wiring time
• Accessible terminals allow for ease of use and are convenient for simple wiring

Product Highlights

The Eaton CN15BN2AB contactor has long life twin break, silver cadmium oxide contacts which provide excellent conductivity and superior resistance to welding and arc erosion.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: CN15BN2AB
• Country of Origin: United States

Technical Specifications

• Coil Power Rating: 1 hp, 2 hp, 3 hp, 5 hp
• Enclosure Type: Open
• Frequency Rating: 50/60 Hz
• Mounting Type: Panel
• Number of Auxiliary Contacts: 1
• Operating Cycles: 3000000 Cycles
• Operating Temperature: -5 to 65 deg C
• Series: Freedom
• Size: 0
• Terminal Type: Screw
• Type: AC Non-Reversing NEMA
• Coil Voltage: 120 VAC
• Maximum Load Current: 18 A
• Contact Configuration: 1NO
• Number of Poles: 2
• Product Name: Eaton Freedom NEMA motor control contactor
• Catalog Number: CN15BN2AB
• UPC: 782113777436
• Product Length/Depth: 3.49 in
• Product Height: 3.88 in
• Product Width: 1.75 in
• Product Type: Motor control contactor
• HP rating - max: 1 hp at 115V, 2 hp at 230,208V, 3 hp at 240V, 5 hp at 480,600V
• Phase: 3
• Amperage Rating: 18A
• Voltage: 600VAC
• Poles: 2NO
• Approval: UL, CSA
• Frame Type: CN15
• Connection Type: Screw
• Terminal Connection: Box Lug
• For Use With: Motor Control Systems
• Temperature Rating: -5 to 65 C
• Mpn: CN15BN2AB
• Alternate Mfr Part Number: CN15BN2AB
• Contact Current Rating: 18 A
• Control Voltage: 120 V
• Current Rating: 18 A
• Description: Eaton Freedom NEMA motor control contactor, NEMA Freedom Series Non-Reversing contactor, 1 hp at 115V, 2 hp at 230,208V, 3 hp at 240V, 5 hp at 480,600V maximum horsepower, 120V/60 Hz or 110V/50 Hz coil voltage, 18A, Two-pole, Size 0
• Special Features: Non-Reversing
• UPC Code: 782113777436
• Manufacturer: Eaton
• Product Series: Freedom
• Family Series: Eaton Contactors, Freedom Series
• Nominal Coil Voltage: 120 VAC
• Coil Type: Magnetic
• Auxiliary Contact: 1NO
• Termination: Box Lug
• Overload Relays: C306, C396
• NEMA Frame Size: 0
