Eaton CCVH2150X CCVH, 2P, 150A, 25kAI

Product Description

Eaton Type CCV Tenant Main Circuit Breaker with MPN CCVH2150X is designed for various applications. It serves as a tenant main breaker in group metering systems and acts as a main or emergency disconnect. Rated at 150 amps and 25 kA interrupt, this two-pole breaker operates on a voltage of 120/240 volts. It accommodates wire sizes from two-aught to three hundred kcmil in both copper and aluminum materials.

• Two-pole design for 120/240 V applications.
• Includes accessories for enhanced functionality.
• Ideal for renewable energy and conventional energy generation.

Product Highlights

This circuit breaker provides reliable protection for electrical systems in commercial and residential settings.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• Voltage Rating: 120/240 V
• Amperage Rating: 150 A
• Wire Size: 2/0 AWG - 300 kcmil
• Number of Poles: 2
• Interrupt Rating: 25 kAIC
• Country of Origin: Dominican Republic
• Dimensions: 7.7 in L x 4.5 in W x 5.4 in H
• Weight: 2.9 lb
• UPC: 786685368498
