EATON CCPLP-3-30CC-P Compact Fused Low Profile Circuit Protector Disconnect Switch

Product Description

The EATON Bussmann CCPLP-3-30CC-P is a compact fused low profile circuit protector disconnect switch. It operates at a voltage of six hundred volts and can manage up to thirty amperes across three poles. The switch is designed for UL Class CC fuses with a wire size range from twenty-two to six American Wire Gauge (AWG).

• Compact design with a footprint suitable for various installations
• High short circuit current ratings (SCCR) up to two hundred kA (UL) and one hundred twenty kA (IEC)
• Front panel mounting for easy access and installation

Product Highlights

This model offers easy integration and is an excellent alternative to traditional circuit breakers.

Product Information

Standard Information

• Brand: EATON
• Manufacturer: EATON

Technical Specifications

• Depth: 3.83 inches
• Height: 2.13 inches
• Width: 2.24 inches
• Voltage Rating: 600 V
• Amperage Rating: 30 A
• Number of Poles: 3
• Fuse Type: Class CC
• Wire Type: Solid Copper/Stranded
• Operating Temperature: -20 to 90 degrees C
• Mounting Type: Front Panel
• Operator: Switch Handle
• Wire Size: 22 to 6 AWG
