Eaton C320KG5 Auxiliary Contact

Product Description

The EATON C320KG5 is an auxiliary contact designed for use with compatible EATON motor starters and contactors. Auxiliary contacts add supplementary switching circuits to a contactor assembly, allowing control wiring to monitor or interlock the main device status without passing load current through the primary poles. Electricians and controls technicians install this type of component in motor control centers, panel boards, and industrial control panels. The C320KG5 is a compact unit measuring 2.6 inches long by 1.1 inches wide by 4.0 inches high and weighs approximately 0.01 pounds.

This auxiliary contact is suited for commercial and industrial electrical installations where supplementary control circuits are required alongside motor starters or contactors. Typical applications include conveyor systems, HVAC motor control panels, pump control panels, and other automated equipment requiring status feedback or interlocking logic at the starter level. It is installed by licensed electricians or qualified controls technicians during new installation or service of motor control equipment.

Key Features

• Supplementary switching circuit capability for interlocking and status monitoring
• Compact form factor: 2.6 x 1.1 x 4.0 inches for tight panel installations
• Lightweight construction at 0.01 pounds
• Designed to mount directly to compatible EATON contactor or starter bodies
• UPC verified unit: 78211337639

Compatibility

Designed as an OEM-style auxiliary contact for use with compatible EATON motor starters and contactors. No specific model compatibility data was provided in the product input; consult EATON documentation or cross-reference guides to confirm fitment with a specific contactor series.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize and lock out the motor control equipment before attaching or removing any auxiliary contact block. Verify that the auxiliary contact block is fully seated and secured to the contactor body before restoring power. Do not exceed the rated switching capacity of the auxiliary contact circuit.

Technical Specifications

• Length: 2.6 inches
• Width: 1.1 inches
• Height: 4.0 inches
• Weight: 0.01 pounds
• UPC: 78211337639

Standard Information

• Brand: EATON
• Manufacturer Part Number: C320KG5
