Eaton BKG2G150B Main Circuit Breaker Kit with Vertical Bottom, 480 VAC, 150 Amp, 35 kAIC

Product Description

The Eaton BKG2G150B is a convertible main and sub-feed circuit breaker kit. This kit is suitable for single-phase or three-phase applications. It operates at a voltage of 480 VAC and has a rating of 150 Amp with a 35 kAIC. The included breaker is classified as PDG23G0150TFFL and can accommodate a wire range of aluminum or copper from one gauge #4 to four aught.

• Designed for both top and bottom mounting
• Globally rated, three-pole 150 Amp breaker
• Includes circuit breaker, line terminals, and load bus connectors

Product Highlights

This product is ideal for electrical assemblies and is compliant with UL 67 standards. The Pow-R-Xpress series ensures reliability and performance for various industrial applications.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part No: BKG2G150B

Technical Specifications

• Amperage Rating: 150
• Voltage: 480 VAC
• kAIC Rating: 35
• Wire Range: AI/Cu (1) #4–4/0
• Type: Convertible Main Circuit Breaker Kit
• Standard: UL 67, NEMA Compliant
• Country of Origin: United States
• Made in USA: Yes
