Eaton B-Line B3050-2X5PLN Clamp Beam 1000Lb

Product Description

The EATON B-LINE B3050-2X5PLN is a beam clamp with an internal brake chopper circuit. It is designed for flange thicknesses of 3/16 to 1/2 inches and supports a 1000 lb load. This clamp is made of steel with a plain finish and is suitable for use with B3210 eye rod, B3211 welded eye rod, and B3200 weldless rye nut, pipe hanger.

• Features an internal brake chopper circuit
• Supports a load of up to 1000 lb
• Recommended for suspending hanger rods from I-beams

Product Highlights

This steel beam clamp is designed for suspending hanger rods from I-beams, equally distributing the load.

Product Information

Standard Information

• Brand: EATON B-LINE
• Manufacturer Part Number: B3050-2X5PLN
• Country of Origin: US

Technical Specifications

• Load: 1000 lb
• Material: Steel
• Finish: Plain
• Thickness: 3/16 to 1/2 in
• Manufacturer: EATON B-LINE
• Product Length/Depth: 1.375 in
• Product Height: 2.125 in
• Product Width: 0.625 in
• Certifications: cULus Listed
• Product Type: Beam clamps
• Application: Suspends hanger rod from I-beam
• Beam/flange width: 0.5 in
• Model: 1/2"-13
• Thread/rod size: 1/2"-13
• Type: Beam clamp
• Load rating/capacity: 1000 lb
• Load capacity: 1000 lb
• SKU: B3050-2X5PLN
• Product Name: Eaton B-Line series beam clamps
• Catalog Number: B3050-2X5PLN
• UPC: 781011023485
• Flange Thickness: 3/16 to 1/2 in
• Series: B3050
• Flange Width: 5 in
• Bolt Size: 1/2-13
• Suitable For Use With: B3210 Eye Rod, B3211 Welded Eye Rod and B3200 Weldless Rye Nut, Pipe Hanger
• Country of Origin: US
• Special Features: Recommended for the suspending of hanger rod from the center of an I-beam, equally distributing the load on both sides of the beam
• Standard: cULus Listed
• Sub_Brand: EATON B-LINE SERIES
• Applications: PIPE HANGERS,MECH.-BEAM CLAMPS
• Brand: B-Line
• Sub Brand: Pipe Hangers
• 12-Digit UPC: 781011023485
• Product UPC: 78101102348
