Eaton AN19DN0E5E045 Solid State Overload Relay 9-45A

Product Description

The EATON AN19DN0E5E045 is a solid state overload relay designed to provide motor protection in industrial and commercial electrical control systems. With an adjustable current range of 9 to 45 amps, this relay monitors motor current and trips the circuit when an overload condition is detected, preventing motor burnout and equipment damage. Solid state technology eliminates mechanical wear points, delivering consistent and reliable trip response over the life of the device. Licensed electricians and industrial maintenance technicians are the primary installers of this type of protective relay.

This overload relay is suited for use in motor control centers, combination starters, and standalone contactor assemblies in light industrial and commercial applications. It is typically installed as part of a full-voltage non-reversing or reversing motor starter circuit controlling three-phase motors across a wide range of horsepower ratings. The broad 9 to 45 amp adjustment range makes it adaptable to multiple motor sizes without requiring a relay change-out at each horsepower step.

Key Features

• Adjustable overload protection range of 9 to 45 amps
• Solid state design eliminates mechanical contacts and reduces maintenance needs
• Provides reliable motor overcurrent and overload trip response
• Suitable for integration into motor control center and starter assemblies
• Weighs 4.18 pounds for straightforward panel mounting

Compatibility

Designed as an OEM-style overload relay for use with compatible EATON motor starters and contactor assemblies requiring a 9 to 45 amp solid state overload protection device.

Installation Notes

Installation should be performed by a qualified licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lockout/tagout the motor control panel before mounting or wiring this relay. Verify the motor full-load amperage rating and set the relay adjustment to match before commissioning the circuit. Do not exceed the maximum current rating of the relay under any operating condition.

Technical Specifications

• Current Range: 9 to 45 amps
• Relay Type: Solid State Overload Relay
• Weight: 4.18 pounds
• UPC: 78668541745

Standard Information

• Brand: EATON
• Manufacturer Part Number: AN19DN0E5E045
