Eaton 13102A6513 Comet Photoelectric Sensor 1.6 in.

Product Description

The EATON 13102A6513 Comet series is a complete line of high-performance, 18 mm tubular photoelectric sensors. These sensors feature selectable Light/Dark operation and have 18mm threaded bodies with flat sides for easy, flexible mounting. It is designed for forward viewing applications with a maximum contact rating of 300 mA.

• Solid Polyurethane Housing Provides Shock and Vibration Resistance
• Visible Beam Models for Easy Sensor Alignment
• 4-Wire DC Models Featuring Both NPN and PNP Outputs

Product Highlights

The sensor can reliably detect targets of different color, reflectance, contrast or surface shape at the same range. Internal components are rigidly sealed in a solid encapsulated package for excellent performance in high vibration and high shock applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: 13102A6513
• Country of Origin: Mexico

Technical Specifications

• Manufacturer Part Number: 13102A6513
• Manufacturer: Eaton
• Product Series: COMET
• Family Series: Eaton Photoelectric Sensors, COMET Series
• Description: Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor dist 1.6 in, 300 mA max AC L1 switched/DC NPN open coll, 300 mA AC/DC at 20-264Vac/15-30Vdc Cable, 20-264 Vac/15-30 Vdc input, Focused Spot Diffuse
• Power Type: AC, DC
• Beam Type: Visible Red
• Max Range: 1.6 "
• Voltage: 15-30 VDC, 20-264 VAC
• Nominal Voltage: 120 VAC, 24 VAC, 24 VDC, 240 VAC, 48 VAC
• Connection Type: 6.6 ft Cable
• Operating Mode: Focused Spot Diffuse
• Output Type: VMOS/NPN
• Max Load Current: 0.5 A
• Composition: Non-Metallic
• Protection Rating: NEMA 1, NEMA 2, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13
• Approvals: CE, CUL, UL
• Construction Style: Barrel/Tubular
• Sensing Range: 1.6 in. (40mm)
• Output Mode: Light/Dark Operate
• Output Configuration: NPN
• Connection Size: M18x1 Thread fits into 0.75 in. (19.1) Dia. Hole
• Sensing Position: Forward Viewing
• Response Time: 10ms/VAC, 1ms/VDC
• Temperature Rating: -40 00b0 to +158 00b0F (-40 00b0 to +70 00b0C)
• Beam Configuration: 0.05 in. (1.3mm) dia. at 1.6 in. (40.0mm)
• Wires - Voltage Type: 3 and 4 Wire AC/DC
• Diameter: 0.47 in. (11.9mm)
• Housing Material: Polyurethane
• Shape: Tubular
• UNSPSC: 39121528
• Application: Automotive, Food Processing and Forest Product Industries, Vehicles On-Road PickUp and Delivery Food Applications
• Enclosure Type: NEMA 1/3/4/4X/6/6P/12/13/IP68/IP69K
• Voltage Rating: 20 to 264 VAC, 15 to 30 VDC
• Frequency Rating: 50/60
• Operating Temperature: -40 to 158
• Size: 18 mm Dia
• Type: 3/4-Wire Forward Viewing
• Series: Comet
• Wattage: 1.5
• Light Source: LED
• Amperage Rating: 300
• Item: Photoelectric Sensor
• Cable Sheath Material: PVC
• Contact Configuration: DC, NPN Open Collector AC, L1 Switched
• Contact Rating: 300 MA AC/DC at 20-264V AC/15-30V DC
• Cord Length: 79.2 ft.
• Enclosure Lens Material: Polycarbonate
• Enclosure Material: Structural Polyurethane Foam
• Input Voltage: 20-264V AC/15-30V DC
• Ip Rating: IP68, IP69K
• Led Indicator: Output Status, Red
• Max. Ac Amps: 300 mA
• Max. Operating Temp.: 158 00b0F
• Maximum Dc Current: 300 mA
• Nema Enclosure Rating: NEMA 1, NEMA 12, NEMA 13, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P
• Operating Temperature - Min: -40 00b0F
• Product Name: Eaton Comet 18mm Tubular Photoelectric Sensor
• Protection Type: Latching Short Circuit
• Sensor Type: Focused Diffuse
• Switch Type: Photoelectric
