Eaton 10316H1004 limit switch

Product Description

The EATON 10316H1004 is a type L limit switch designed for chassis mounting. It features an SPDT circuit and an On-On switch function. The switch operates effectively in temperatures ranging from -29°C to 93°C. It is suitable for various applications requiring reliable switching performance.

• Chassis mount
• SPDT circuit
• Screw terminal

Product Highlights

This limit switch offers a side rotary actuator without a lever and supports both AC and DC voltage ratings.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10316H1004

Technical Specifications

• Manufacturer: Eaton Electrical
• Packaging: Bulk
• Current Rating (Amps): 10A (AC), 200mA (DC)
• Mounting Type: Chassis Mount
• Circuit: SPDT
• Switch Function: On-On
• Operating Temperature: -29°C ~ 93°C
• Termination Style: Screw Terminal
• Actuator Type: Side Rotary - No Lever
• Voltage Rating - AC: 600 V
• Voltage Rating - DC: 125 V
