Eaton 10250TS83 Pushbutton Legend Plate TEST

Product Description

The Eaton 10250TS83 is a push button legend plate used for 10250T series, pushbutton operators and indicating lights. It features a heavy-duty zinc die cast construction. Reliability nibs improve contact reliability even under dry circuit and fine dust conditions. Drainage holes prevent the buildup of liquid inside the operator.

• Push button legend plate
• Panel mounting type
• Used for 10250T series, pushbutton operators and indicating lights

Product Highlights

The Eaton 10250TS83 legend plate has printed text to provide information about a push button's function.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS83
• Country of Origin: Dominican Republic

Technical Specifications

• Product Name: Eaton 10250T pushbutton legend plate
• Catalog Number: 10250TS83
• UPC: 782113134017
• Product Length/Depth: 1.7 in
• Product Height: 0.1 in
• Product Width: 1.7 in
• Compliances: CE Marked
• Certifications: UL Listed CSA Certified
• Catalog Notes: Has a satin aluminum field. Color is on lower portion.
• Product Type: Pushbutton accessory
• Used with: 10250T series, pushbutton operators and indicating lights
• Series: 10250T Series
• Field color: Black
• Legend: TEST
• Letter size: 3/16 in high
• Lettering color: White
• Size: Standard, square
• Brand: Eaton/Cutler-Hammer
• Mounting Type: Panel
• Approval: UL, CSA, CE
• Length (in): 1.7
• Width (in): 1.7
• Height (in): 0.1
• For Use With: 10250T Series, Pushbutton Operators and Indicating Lights
• Mpn: 10250TS83
• Upc: 782113134017
• Gtin: 00782113134017
• Alternate Mfr Part Number: 10250TS83
• Dimensions: 0.01 in W X 1.70 in L
• Manufacturer Part Number: 10250TS83
• Type: Pushbutton accessory
• UPC Code: 782113134017
• SKU: CS3567078
• Field Color: Black
• Compatible with Series: 10250T
• Background Color: Black
• Keyway Type: Notch
• Language: English
• Legend Color: White
• Material: Aluminum
• Overall Height: 1-3/4 in
• Overall Width: 1-3/4 in
• Panel Mounting Hole Diameter: 30 mm
• Shape: Square
