Eaton 10250TS42 Standard Type 30.5mm Selector Switch

Product Description

The EATON 10250TS42 is a standard-type selector switch operator designed for 30.5mm control stations and pendant enclosures. This operator interfaces with compatible contact blocks to form a complete selector switch assembly used in industrial control circuits. It provides reliable manual switching action for machine control, motor starters, and panel-mounted operator interfaces. The 10250TS42 is a compact, lightweight component weighing 0.010 pounds, with an overall footprint of 1.7 inches by 1.7 inches and a depth of 0.1 inches, making it well suited for tight panel layouts where space is at a premium. Electricians and controls technicians are the primary installers of this type of operator.

This selector switch operator is used in industrial and commercial electrical control panels, machine tool enclosures, and operator stations. It is appropriate for applications requiring manual position selection in motor control centers, conveyor systems, and general-purpose industrial machinery. The 30.5mm mounting format is a widely used standard in industrial control equipment, allowing this operator to fit into a broad range of existing panel cutouts and modular control station assemblies.

Key Features

• Standard-type selector switch operator with 30.5mm mounting diameter
• Compact profile at 0.1 inches depth, suitable for shallow enclosures
• Lightweight construction at 0.010 pounds for minimal panel loading
• Designed to mate with compatible 10250T-series contact blocks for circuit completion
• UPC: 78211336061 for accurate procurement and inventory tracking

Compatibility

Designed as a standard-type operator for 30.5mm industrial control stations. Specific compatible contact blocks and enclosures were not provided in the product data; consult EATON documentation for complete assembly compatibility within the 10250T series.

Installation Notes

Installation of selector switch operators should be performed by a qualified electrician in accordance with applicable NEC requirements. De-energize and lock out the control panel before removing or installing any operator or contact block. Ensure the 30.5mm panel cutout is clean and within tolerance before mounting to guarantee proper seating and operator function. Do not overtighten the mounting hardware, as this can crack the operator body or distort the panel.

Technical Specifications

• Mounting Diameter: 30.5mm standard type
• Dimensions (L x W x H): 1.7 inches x 1.7 inches x 0.1 inches
• Weight: 0.010 pounds
• UPC: 78211336061

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS42
