Eaton 10250TS33 Standard Type Pushbutton Operator

Product Description

The EATON 10250TS33 is a standard-type pushbutton operator designed for use in industrial control panels and operator interface stations. This component serves as the actuator portion of a pushbutton assembly, providing the mechanical interface between the operator and the switching contact block mounted behind it. Built to the 30.5mm form factor, the 10250TS33 fits the 10250T series mounting platform and is installed by licensed electricians and industrial controls technicians. Compact and lightweight at 0.010 pounds, it fits within tight panel layouts without sacrificing durability or function.

This operator is suited for industrial and commercial electrical control applications where panel-mounted pushbutton assemblies are required. Typical installations include motor control centers, machine control panels, and operator interface enclosures. The 30.5mm mounting diameter is a widely used standard in industrial controls, making this operator a practical fit for new builds and retrofit panel work alike.

Key Features

• Standard-type pushbutton operator in the 30.5mm mounting class
• Part of the EATON 10250T series operator interface platform
• Compact footprint: 1.7 inches x 1.7 inches x 0.1 inches
• Lightweight construction at 0.010 pounds
• Designed for pairing with compatible 10250T series contact blocks and accessories

Compatibility

Designed as an OEM-style operator for use within the EATON 10250T series 30.5mm pushbutton platform, compatible with corresponding 10250T series contact blocks and mounting hardware.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the control panel and verify zero voltage before servicing any operator or contact block assembly. The operator typically mounts through a panel cutout and secures with the appropriate 10250T series mounting hardware before the contact block is attached from the rear. Avoid over-tightening the mounting nut, which can crack the operator body or distort the panel face.

Technical Specifications

• Series: 10250T Standard Type
• Mounting Diameter: 30.5mm
• Dimensions (L x W x H): 1.7 inches x 1.7 inches x 0.1 inches
• Weight: 0.010 pounds
• UPC: 78211336052

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS33
