Eaton 10250TS26 Standard Push Button Operator 30.5mm

Product Description

The EATON 10250TS26 is a standard-type push button operator designed for use in industrial control and signaling applications. This operator fits 30.5mm mounting cutouts and serves as the actuator component in a push button station assembly. At 0.01 pounds and measuring 1.7 inches by 1.7 inches by 0.1 inches, it is a compact, lightweight device intended for panel-mount installations. Licensed electricians and industrial control technicians install this operator as part of a complete operator-contact block assembly on machine control panels, motor control centers, and similar industrial enclosures.

This push button operator is suited for standard industrial control panel applications in manufacturing, process control, and machine automation environments. It is installed into 30.5mm diameter panel cutouts, which is the most common aperture size in industrial operator interface hardware. The 10250TS26 is part of the EATON 10250T series of heavy-duty industrial operators and is intended for use with compatible contact blocks from the same series.

Key Features

• Standard-type push button operator for 30.5mm panel cutouts
• Compact profile at 1.7 inches x 1.7 inches x 0.1 inches
• Lightweight construction at 0.01 pounds
• Designed for use with compatible 10250T series contact blocks
• Suitable for industrial control panel and machine interface applications

Compatibility

Designed as a standard-type operator for 30.5mm industrial push button station assemblies, intended for use with compatible contact blocks in the EATON 10250T series platform.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the panel before installing or removing the operator. The operator mounts through a 30.5mm panel cutout and secures with the appropriate retaining hardware before the contact block is attached to the rear. Do not force-fit the operator into undersized or damaged cutouts.

Technical Specifications

• Mounting Cutout Size: 30.5mm
• Length: 1.7 inches
• Width: 1.7 inches
• Height: 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211336045

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS26
