Eaton 10250TM54 Standard Type Pilot Light Lens 30.5mm

Product Description

The EATON 10250TM54 is a standard-type pilot light lens designed for 30.5mm operator devices used in industrial control panels and machine control applications. This replacement lens fits into the 10250T series pushbutton and pilot light assemblies, providing the transparent cover that protects the lamp while allowing the indicator light to remain visible to the operator. Electricians and panel builders install this component during new panel builds or as a field replacement when an existing lens becomes cracked or discolored. At 0.01 pounds, it is a lightweight, precision-fit part.

This lens is suited for industrial environments where 30.5mm control stations are standard. Typical applications include motor control centers, machine tool panels, conveyor control systems, and other operator interface stations requiring reliable visual indication. The 10250TM54 is installed as part of a complete pilot light assembly and is not a standalone electrical component.

Key Features

• Standard-type lens for 30.5mm pilot light and pushbutton assemblies
• Low-profile construction at 0.1 inches depth
• Compact footprint measuring 1.7 inches by 1.6 inches
• Lightweight at 0.01 pounds for easy handling during panel assembly
• Designed for use with EATON 10250T series operator devices

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T series 30.5mm pilot light and pushbutton assemblies used in industrial control panel applications.

Installation Notes

Installation is typically performed by a licensed electrician or qualified panel builder. De-energize and lock out the control panel per NFPA 70E procedures before servicing any operator device. The lens snaps or threads into the pilot light body depending on the assembly style. Inspect the lamp socket and body for damage before installing the replacement lens.

Technical Specifications

• Operator Size: 30.5mm
• Type: Standard
• Length: 1.7 inches
• Width: 1.6 inches
• Height/Depth: 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211322451

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM54
