Eaton 10250TM50 Standard Type Pushbutton Operator

Product Description

The EATON 10250TM50 is a standard-type pushbutton operator designed for use in industrial control and automation applications. This 30.5mm operator mounts into standard panel cutouts and serves as the human-machine interface point for starting, stopping, or signaling control circuits. Licensed electricians and industrial controls technicians typically install and maintain these devices. The compact form factor and standardized mounting dimensions make it a straightforward panel-building component suited for both new installations and replacement applications.

The 10250TM50 fits into industrial control panels, machine operator stations, and enclosure-mounted control assemblies. It is appropriate for use in light manufacturing, process control, and general-purpose industrial environments where a 30.5mm panel-mount operator is required. This operator is installed in conjunction with matching contact blocks and legend plates to complete a functional pushbutton assembly.

Key Features

• 30.5mm standard mounting diameter for broad panel compatibility
• Compact profile at approximately 1.7 x 1.6 x 0.1 inches
• Lightweight construction at 0.01 pounds
• Standard type operator suitable for general industrial control use

Compatibility

Designed as an OEM-style replacement or new-installation operator for industrial control panels and operator stations requiring a 30.5mm standard-type pushbutton operator.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the NEC and applicable local codes. De-energize the panel and verify absence of voltage before installing or replacing any operator or contact block. Ensure the panel cutout meets the 30.5mm diameter specification before mounting. Do not overtighten the mounting nut, as doing so may crack the operator body or distort the panel.

Technical Specifications

• Mounting Diameter: 30.5mm
• Dimensions (L x W x H): 1.7 x 1.6 x 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211322448

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM50
