Eaton 10250TM26 Standard Type Pilot Light Module

Product Description

The EATON 10250TM26 is a standard-type pilot light module designed for use in 30.5mm pushbutton operator assemblies. This modular legend plate or indicator insert mounts directly into compatible 10250T-series operator bases, providing status indication for industrial control panels and operator interface stations. At 0.01 pounds and measuring 1.7 inches long by 1.6 inches wide by 0.1 inches deep, the unit is a compact, drop-in component. Licensed electricians and industrial control panel builders handle installation as part of larger pushbutton or selector switch assemblies in factory automation, motor control, and machinery safety circuits.

The 10250TM26 fits into 30.5mm industrial control station assemblies commonly found in manufacturing environments, motor control centers, and machine control panels. It is intended for use with EATON 10250T-series operators and control station enclosures. This module is typically installed during panel build or field service when replacing worn legend or indicator components in an existing operator assembly.

Key Features

• Standard-type module for 30.5mm operator assemblies
• Compact footprint: 1.7 inches x 1.6 inches x 0.1 inches
• Lightweight at 0.01 pounds for easy handling during panel assembly
• Designed for modular integration into 10250T-series control stations
• UPC: 78211320361

Compatibility

Designed as an OEM-style replacement module for EATON 10250T-series 30.5mm pushbutton and operator control station assemblies.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NFPA 70 (NEC) requirements. De-energize the control circuit and verify zero voltage at the panel before disassembling the operator station. The module snaps or fastens into the operator base without special tools. Verify correct seating and secure any retaining hardware before restoring power.

Technical Specifications

• Operator Size: 30.5mm
• Module Type: Standard Type
• Length: 1.7 inches
• Width: 1.6 inches
• Height: 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211320361

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM26
