Eaton 10250TM25 Standard Type Pushbutton Operator

Product Description

The EATON 10250TM25 is a standard-type pushbutton operator in the 30.5mm format, designed for use in industrial control panel applications. This operator mounts into standard 30.5mm cutout enclosures and serves as the physical actuator component in a pushbutton station assembly. Electrically licensed panel builders and industrial electricians install this type of operator when wiring machine control, motor control centers, or operator interface stations. At 0.1 pounds, it is a compact, lightweight component suited for high-density panel layouts.

The 10250TM25 fits into the 30.5mm operator series commonly found in industrial and commercial electrical control applications. It is appropriate for new panel builds and replacement service on existing 30.5mm pushbutton stations. Electricians and panel builders working on machine control, process equipment, or motor starters will encounter this operator format regularly in the field.

Key Features

• 30.5mm standard mounting format for broad enclosure compatibility
• Compact footprint: 1.5 inches long x 1.7 inches wide x 0.1 inches deep
• Lightweight at 0.1 pounds for high-density panel installations
• Standard operator type suitable for momentary pushbutton station assemblies

Compatibility

Designed as an OEM-style operator for 30.5mm pushbutton station assemblies typical of industrial control panel applications.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC guidelines. De-energize and lock out the control panel before removing or installing any operator or contact block. Ensure the mounting cutout conforms to the 30.5mm standard before seating the operator. Do not over-tighten the mounting hardware, as this can crack the operator body or deform the panel surface.

Technical Specifications

• Operator Type: Standard
• Mounting Format: 30.5mm
• Dimensions (L x W x H): 1.5 inches x 1.7 inches x 0.1 inches
• Weight: 0.1 pounds
• UPC: 78211320360

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM25
