Eaton 10250TM16 Standard Type Pilot Light Lens

Product Description

The EATON 10250TM16 is a standard-type pilot light lens designed for use with 30.5mm push button and pilot light operator assemblies. This lens fits into the front of an indicator light or illuminated operator housing, diffusing or transmitting light from the lamp module behind it. Electricians and panel builders install this component during new panel builds or as a replacement when an existing lens becomes cracked, discolored, or damaged. At 0.010 pounds and measuring approximately 1.7 x 1.6 x 0.1 inches, it is a compact, low-profile accessory that drops into compatible 30.5mm operator stations.

This lens is suited for industrial control panels, machine operator stations, and push button enclosures using the 30.5mm mounting standard. It is typically found in manufacturing, process control, and utility environments where visual status indication is required at the operator interface. Panel builders and maintenance electricians replace these lenses during routine refurbishment of control stations or after physical damage from impact or exposure.

Key Features

• Standard-type lens for 30.5mm pilot light and push button operator assemblies
• Compact profile at 1.7 x 1.6 x 0.1 inches for direct drop-in replacement
• Lightweight construction at 0.010 pounds, adding negligible load to the operator housing
• UPC: 78211322428 for positive product identification at receiving

Compatibility

Designed as an OEM-style replacement lens for EATON 30.5mm pilot light and illuminated operator assemblies in the 10250T series product family.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC guidelines. De-energize the control panel and verify zero voltage with a meter before opening the enclosure or handling any operator components. The lens typically snaps or threads into the operator cap without special tools. Inspect the lamp module and socket contacts while the station is open to confirm serviceability before closing the enclosure.

Technical Specifications

• Mounting Size: 30.5mm
• Dimensions (L x W x H): 1.7 x 1.6 x 0.1 inches
• Weight: 0.010 pounds
• UPC: 78211322428

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TM16
