Eaton 10250TJ37 Jumbo 30.5 Mm Push Button Operator

Product Description

The EATON 10250TJ37 is a jumbo-type operator designed for 30.5 mm push button control stations. This component serves as the actuating mechanism in industrial control circuits, providing the physical interface between the operator and the control panel's switching element. It mounts into a standard 30.5 mm cutout and is built for demanding industrial environments where reliable actuation is required. Electricians and control panel technicians install this type of operator as part of motor control, machine tool, and process control wiring schemes. The compact profile measures 2.2 inches by 2.0 inches by 0.1 inches and weighs under 0.1 pounds.

This operator is suited for use in industrial and commercial control panel applications where a 30.5 mm mounting footprint is specified. Typical installations include motor starter stations, emergency stop assemblies, and general-purpose machine control enclosures. It pairs with compatible contact blocks and legend plates within the 10250T series product family as detailed in the manufacturer's documentation.

Key Features

• Jumbo-type form factor for increased operator visibility and ease of actuation
• Designed for standard 30.5 mm panel cutout mounting
• Low-profile construction at 0.1 inches depth behind panel face
• Lightweight at 0.010 pounds for minimal enclosure load
• Compatible with 10250T series contact blocks and accessories

Compatibility

Designed as an OEM-style operator for 30.5 mm industrial push button control stations. Refer to EATON 10250T series documentation for specific compatible contact blocks, enclosures, and legend plates.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the control panel before removing or installing any operator or contact block. Ensure the panel cutout conforms to the 30.5 mm specification before mounting. Do not force the operator into an incompatible cutout, as this may damage the contact block or operator body.

Technical Specifications

• Operator Type: Jumbo Type
• Mounting Diameter: 30.5 mm
• Dimensions (L x W x H): 2.2 inches x 2.0 inches x 0.1 inches
• Weight: 0.010 pounds
• UPC: 78211320443

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TJ37
