Eaton 10250T197LRP2A Standard Pushbutton Operator

Product Description

The EATON 10250T197LRP2A is a standard-type pushbutton operator designed for industrial control panel and machine control applications. Pushbutton operators serve as the human interface point in control circuits, allowing operators to initiate or interrupt electrical signals in low-voltage control systems. This unit is part of the Eaton 10250T series, a well-established product family used in panel-mounted operator interface assemblies. The compact footprint and standard mounting profile make it suitable for integration into new builds or direct replacement of worn or damaged operators on existing equipment. Licensed electricians and industrial control technicians are the primary installers.

The 10250T197LRP2A fits standard industrial control panel applications where a reliable, panel-mounted pushbutton operator is required. Typical install scenarios include motor control panels, machine control enclosures, and process control stations in both light and heavy industrial environments. No specific compatible model numbers or system families were stated in the available product data beyond the 10250T series designation.

Key Features

• Standard-type pushbutton operator in the Eaton 10250T series
• Compact dimensions of 2.4 inches x 2.1 inches x 3.2 inches for panel-mount integration
• Lightweight at 0.4 pounds for easy handling and installation
• Designed for industrial control circuit and machine interface applications

Compatibility

Designed as an OEM-style replacement or new-installation pushbutton operator compatible with standard 10250T series operator interface assemblies and control station enclosures where this series is specified.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements and the panel or equipment manufacturer guidelines. De-energize the control circuit and lock out or tag out the equipment before removing or installing any operator device. Verify panel cutout dimensions and operator series compatibility before installation. Do not apply force to seat the operator if resistance is encountered, as this may indicate a mounting or fitment mismatch.

Technical Specifications

• Dimensions (L x W x H): 2.4 inches x 2.1 inches x 3.2 inches
• Weight: 0.4 pounds
• UPC: 78211471114

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250T197LRP2A
