Eaton 10250H5104 Pushbutton STOP

Product Description

The Eaton 10250H5104 pushbutton is an assembled control station designed for heavy-duty applications. This 30.5 mm pushbutton features a die-cast enclosure and an extended red actuator with a STOP legend. It is NEMA 1 rated and includes one element for surface mounting. It improves contact reliability even under dry circuit and fine dust conditions.

• Heavy-duty zinc die-cast construction
• Enclosed silver contacts with reliability nibs
• Diaphragm seals with drainage holes

Product Highlights

This Eaton pushbutton is ideal for demanding environments requiring a robust and reliable control station.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250H5104
• Country of Origin: Dominican Republic

Technical Specifications

• Catalog Number: 10250H5104
• UPC: 782113223308
• Product Length/Depth: 4.7 in
• Product Height: 2.4 in
• Product Width: 2.1 in
• Compliances: CE Marked
• Certifications: CSA Certified UL 505
• Catalog Notes: Black Bezel
• Product Type: Pushbutton
• Type: 30.5 mm, Heavy-Duty
• Actuator color: Red
• Enclosure: NEMA 1
• Actuator: Extended
• Enclosure material: Die cast
• Legend: STOP
• Lens material: Plastic
• Series: 10250H
• Product category: Assembled control station
• Number of elements: 1
• Mounting method: Surface
• Model: 10250H5104
• MPN: 10250H5104
• Brand: Eaton
• Country of Origin: Dominican Republic
• Condition: New
• UNSPSC: 39121565
• Material: Die Cast
• Mounting Type: Surface
• Operator Type: Extended Pushbutton
• Contact Configuration: 1NC
• Dimensions: 4.7 in L x 2.1 in W x 2.4 in H
• (Switching-Indication) Size: 30.5 mm
• Manufacturer: Eaton
• Product Series: 10250H
• Family Series: Eaton Switches, 10250H Series
• Illuminated: No
• Mounting: 30 mm
• Bezel: Metal Round
• Lens/Button Shape: Round Extended
• Operator Color: Red
• Terminal Type: Screw
• NEMA Rating: NEMA 1
• Approvals: UL
• Comments: Legend: STOP
