E.r. Wagner 1F2805027002197 Swivel Top Plate Caster 350 Lb

Product Description

The E.R. WAGNER 1F2805027002197 is a swivel top plate caster designed for industrial and commercial material-handling applications. It features a 5-inch polyolefin wheel with a 1-3/8-inch width, a 350-pound load capacity, and a side brake for controlled stopping. The zinc-finished steel plate and hardened, heat-treated construction are built to withstand repeated use in demanding environments. At 6-1/16 inches overall height, this caster suits standard cart and equipment builds. It is installed by maintenance technicians, industrial equipment assemblers, and facility operations crews.

This caster is engineered for use on carpeted surfaces, making it well suited for office furniture, carts, and equipment dollies deployed in carpeted commercial or institutional spaces. The polyolefin wheel is gentle on carpet fibers while still supporting heavy loads. The swivel mount allows full 360-degree rotation for easy repositioning of equipment. The side brake engages to hold the caster stationary when the load is parked, which is important in environments where unintended movement is a safety concern.

Key Features

• 5-inch polyolefin wheel rated for carpeted surface applications
• 350-pound load capacity with hardened, heat-treated construction
• Side brake for positive locking when stationary
• Zinc-finished top plate resists corrosion in light-duty environments
• Plain bearing provides smooth, low-maintenance swivel action
• Compact 3-1/8 inch x 4-1/8 inch mounting plate fits standard equipment frames

Compatibility

Designed as an OEM-style replacement or new-build caster for carts, dollies, and light industrial equipment requiring a swivel top plate mount with a 3-1/8 inch x 4-1/8 inch bolt pattern.

Installation Notes

Installation is performed by maintenance technicians or equipment assemblers using standard hand tools. Ensure the mounting surface is flat and that fastener holes align with the 3-1/8 inch x 4-1/8 inch plate pattern before securing hardware. Remove all load from the equipment before replacing an existing caster. Verify that the total combined caster load rating meets or exceeds the maximum loaded weight of the equipment before placing into service.
