E. James 5L980 V-Belt

Product Description

The E. JAMES 5L980 V-Belt is suitable for industrial and light-duty tasks, including work with fractional horsepower motors. This belt includes flex-bonded cords that help distribute load and absorb bending stress.

• Constructed with a protective cover against oil, dirt, and heat.
• Compliant with ARPM/RMA standards for oil resistance and static conductivity.
• Fit for applications that utilize backside idlers.

Product Highlights

The E. JAMES V-Belt is designed for general industrial applications, constructed with a smooth backside for efficient operation.

Product Information

Standard Information

• Brand: E. JAMES
• MPN: 5L980

Technical Specifications

• Belt Type: 5L
• Material: Rubber, Polyester
• Effective Length: 97.93 inches
• Thickness: 9 mm
• Top Width: 0.656 inches
• Maximum Operating Temperature: 194°F
• Minimum Operating Temperature: -22°F
• Resistance Features: Heat, Oil, Static Conductive
