E. James 5L470 V-Belt

Product Description

The E. James 5L470 V-Belt is designed for industrial and light-duty applications, including fractional horsepower motors. This belt is specifically optimized for shorter center distances and high-speed operation. It features flex-bonded cords that ensure equal load distribution and absorb bending stress effectively.

• Flex-Weave cover extends lifespan by providing protection from oil, dirt, and heat.
• Constructed with high-strength polyester cords for resistance to fatigue and stretch.
• Meets RMA standards for oil and heat resistance and static conductivity.

Product Highlights

The E. James 5L470 V-Belt is suitable for applications involving backside idlers. It offers a robust design that dissipates heat effectively while maintaining durability.

Product Information

Standard Information

• Brand: E. James
• Part Number: 5L470

Technical Specifications

• Strand: 1
• Top Width: 21/32 inches
• Length: 47 inches
• Section: 5L
• Construction: Smooth
• Name: Truflex
• Category: V-Belts
• Color: Black
• Height: 0.375 inches
• Nominal Outside Length: 1193.8 mm
• Weight: 0.47 lbs
• Width: 0.66 inches
