E. James 5L320 V-Belt Fractional Horsepower V-Belt

Product Description

The E. James 5L320 is a fractional horsepower V-belt suitable for general industrial use. This V-belt features wrapped construction, enhancing its durability, and is manufactured using rubber and polyester materials. It is part of the Duraflex GL series and offers resistance to heat, oil, and static conductivity. The product complies with ARPM standards and has a tensile strength of five thousand four hundred N/mm.

• Wrapped edge construction for increased reliability.
• Minimum pulley pitch diameter requirement of three point five inches.
• Operates effectively within a temperature range of minus twenty-two degrees Fahrenheit to one hundred ninety-four degrees Fahrenheit.

Product Highlights

This V-belt is designed to efficiently meet the needs of various applications in industrial settings.

Product Information

Standard Information

• Item: FHP V-Belt
• Brand: E. James

Technical Specifications

• Belt Type: 5L
• Construction: Wrapped
• Industry Number: 5L320
• Material: Rubber, Polyester
• Number of Ribs: 1
• Outside Length: 32
• Thickness: 3/8
• Top Width: 0.656
• Application: General Industrial
• Belt Coating: Rubber
• Belt Material: Gum Rubber
• Belt Series: Duraflex GL
• Edge Construction: Wrapped
• Minimum Pulley Pitch Diameter: 3.5
• Length Type: Closed Loop
• Maximum Operating Temperature: 194°F
• Minimum Operating Temperature: -22°F
• Reinforcing Cord Material: Polyester
• Resistance Properties: Heat, Oil, Static Conductive
• Standards: ARPM
• Tensile Strength: 5400 N/mm
• V-belt Section: 5L
• V-belt Type: Fractional Horsepower
