E-Flex 24102 LA Conduit 1-1/4 Inch

Product Description

The E-FLEX 24102 LA conduit offers outstanding protection against wet, oily conditions and is permitted for use in exposed or concealed locations. The jacketing material is a high-quality, rugged, flame-retardant PVC compound that resists oils, mild acids, and exposure to sunlight. RoHS and WEEE compliant.

• Outstanding protection against wet, oily conditions
• Permitted for use in exposed or concealed locations
• High quality, rugged, flame retardant PVC compound jacketing

Product Highlights

Flexible steel conduit with PVC jacket, resistant to oils and mild acids, and suitable for wet locations.

Product Information

Standard Information

• Brand: E-FLEX
• Manufacturer Part Number: 24102
• Country of Origin: USA

Technical Specifications

• Manufacturer Part Number: LA-14
• Manufacturer: Electri-Flex
• Product Series: LA
• Family Series: Electri-Flex Conduit, LA Series
• Description: Conduit, 1-1/4in., LA, Gray, Jacketed, Metallic, Steel, PVC, -20_60, Liquitight
• Trade Size: 1-1/4 in.
• Diameter: 1.66 "
• Feet/Pkg.: 50 '
• Inside Bend Radius: 7 in.
• Material: Steel
• Jacket Material: Polyvinyl Chloride
• Operating Temperature: -4-140 °F
• Special Properties: Acid Resistant, Oil Resistant
• Conduit Type: Jacketed Metallic Flexible
• Liquid Tight: Yes
• Approvals: CSA, UL
• Net Weight: 1 lb
• Gross Weight: 1 lb
• Country of Origin: United States
• Standard Colors: Machine Tool Gray and Black. Other colors available upon request.
• Working Temperatures: -30°C to 80°C Dry / 60°C Wet / 70°C Oil
• Type: LA
• Length: 50 ft.
• Weight: 102 lbs./100ft
• Outside Diameter Maximum: 1.660 in.
• Inside Diameter Minimum: 1.38 in.
• Inside Diameter Maximum: 1.41 in.
• Outside Diameter Minimum: 1.630 in.
• Inner Core: Hot Dipped Galvanized Steel
• Liquidtight Jacket: Flexible PVC
• Resistant to: Oils and Mild Acids
• Flame Retardant: Yes
• Sunlight Resistance (UV): Excellent
• Bend Radius: 7 in
• Brand: Liquatite
• Sub Brand: Liquatite
• 12-Digit UPC: 782673241026
• Product UPC: 78267324102
• Buy American Compliant: Y
• CA Prop65 Warning: This product is in compliance with Prop65; it is not known to contain any chemicals associated with this regulation.
• Standards and Certifications: ARRA Compliant, BAA Compliant, PROP65, UL, CSA, CE, E29278, LL18858 C22.2 No 56-17, BS EN IEC 61386 Classification Code 444240650414, EU RoHS Indicator
