Dynaflux UVGO4512GF Gold Glass Filter Plate Shade 12

Product Description

The DYNAFLUX UVGO4512GF is a heat-treated gold glass filter plate designed for use in welding helmets and face shields. It measures 4.5 inches x 5.25 inches and carries a Shade 12 rating, making it appropriate for arc welding applications that require significant optical protection from UV and infrared radiation. The gold tint is achieved through a heat treatment process applied to the glass, delivering consistent light reduction across the filter surface. Installation is straightforward and intended for licensed welding professionals or qualified technicians performing lens replacement in standard-format helmet filter frames.

This filter plate is suited for arc welding environments including MIG, TIG, and stick welding operations where Shade 12 optical density is specified by procedure or safety standard. The 4.5-inch x 5.25-inch format is a common size used in passive welding helmets and goggles. Welding contractors, fabrication shops, and industrial maintenance crews are the primary users. The gold glass construction provides UV and IR filtering without electronic auto-darkening components, making it a reliable passive-protection replacement lens.

Key Features

• Heat-treated gold glass construction for consistent optical density
• Shade 12 rating suitable for higher-amperage arc welding processes
• 4.5 inches x 5.25 inches format fits standard passive helmet filter frames
• Filters both UV and infrared radiation during welding operations
• Sold individually, allowing single-unit replacement

Compatibility

Designed as an OEM-style replacement gold glass filter plate for standard passive welding helmets and face shields accepting a 4.5-inch x 5.25-inch filter lens.

Installation Notes

Filter plate replacement should be performed by a qualified welding professional or safety equipment technician. Ensure the welding helmet or face shield is fully removed from service and cleaned before installing the new lens. Handle glass filter plates by the edges to avoid surface contamination that can affect optical clarity. Verify that the installed shade rating meets the requirements of the applicable welding procedure specification and ANSI Z87.1 or applicable safety standard before returning the equipment to service.

Technical Specifications

• Shade Rating: 12
• Dimensions: 4.5 inches x 5.25 inches
• Weight: 0.05 pounds
• Lens Material: Heat-treated gold glass
• Unit of Measure: Each

Standard Information

• Brand: DYNAFLUX
• Manufacturer Part Number: UVGO4512GF
