Dwyer Instruments tl25-060-4b Pressure Gauge 60 Psi

Product Description

The DWYER INSTRUMENTS tl25-060-4b is a utility water pressure gauge designed for monitoring water system pressure in plumbing and mechanical applications. It features a 2.5 inch dial face with a 0 to 60 psi range and a 0.25 inch male pipe thread back mount connection. The back mount configuration positions the inlet at the rear of the gauge, keeping the face fully visible when installed in tight panel or pipe locations. This gauge is a standard field instrument for licensed plumbers and HVAC technicians performing pressure testing, system commissioning, and routine service work.

This gauge is suited for residential and light commercial water systems where a compact, easy-to-read dial instrument is needed at a fixed monitoring point. The back mount entry makes it a practical choice for manifolds, boiler systems, and pressure panels where a lower-profile installation is required. It is typically installed by plumbers or mechanical contractors as a permanent system indicator or a bench reference gauge during service calls.

Key Features

• 60 psi range provides clear resolution for typical domestic and light commercial water pressure monitoring
• 2.5 inch dial face offers easy readability in confined mechanical spaces
• 0.25 inch male pipe thread (MPT) back mount connection for direct in-line or manifold installation
• Utility-grade construction suited for water service environments
• Compact form factor fits standard panel cutouts and close-clearance pipe arrangements

Compatibility

Designed as an OEM-style replacement or direct-install utility pressure gauge for residential and light commercial water plumbing systems requiring a 0.25 inch MPT back mount connection and a 60 psi range.

Installation Notes

Installation is performed by a licensed plumber or qualified mechanical technician. Shut off water supply and relieve system pressure completely before removing an existing gauge or making new connections. Apply thread sealant tape or pipe dope to the MPT threads per local plumbing code before threading into the fitting. Do not over-tighten; use a wrench on the gauge body hex, not the dial housing.

Technical Specifications

• Pressure Range: 0 to 60 psi
• Dial Size: 2.5 inches
• Connection Size: 0.25 inches MPT
• Mount Type: Back Mount
• Media: Water

Standard Information

• Brand: DWYER INSTRUMENTS
• Manufacturer Part Number: tl25-060-4b
