Dwyer 2000-0AV Air Filter Kit 15 Psi 1/8 Npt

Product Description

The DWYER 2000-0AV is an air filter kit designed for use in low-pressure pneumatic instrument lines and air supply systems. It filters airborne particulates and moisture from instrument air supplies, helping protect downstream gauges, transmitters, and control devices from contamination. The unit accepts 1/8 inch NPT threaded connections and handles a maximum operating pressure of 15 psi. With a stated accuracy of 2%, it suits general-purpose instrument air applications. Licensed HVAC technicians, instrumentation techs, and industrial service professionals typically install this type of filter kit as part of a clean, regulated air supply circuit.

This air filter kit is suited for low-pressure instrument air lines in residential, commercial, and light industrial environments. Typical applications include protecting pneumatic control systems, air-operated valves, and pressure sensing instruments. The 1/8 inch NPT thread size makes it compatible with standard small-bore instrument tubing fittings and manifolds. The kit is packaged as a single unit and is appropriate for new installations or direct replacement of worn or clogged inline air filters in existing pneumatic supply lines.

Key Features

• 15 psi maximum operating pressure for low-pressure pneumatic instrument air service
• 2% accuracy rating for reliable general-purpose filtration applications
• 1/8 inch NPT threaded connection for standard small-bore instrument fittings
• Compact kit format — packaged as a single complete unit
• Rated to 140 degrees F maximum temperature for typical indoor mechanical room environments

Compatibility

Designed as an OEM-style replacement or new-install air filter kit for low-pressure pneumatic instrument air supply lines using 1/8 inch NPT threaded connections at pressures up to 15 psi.

Installation Notes

Installation should be performed by a qualified HVAC technician or instrumentation professional familiar with pneumatic control systems. Shut off the instrument air supply and bleed residual pressure from the line before removing or installing the filter. Use appropriate thread sealant on NPT connections and avoid over-tightening, which can crack filter bowl housings. Verify all connections are leak-free before returning the air supply to service.
