DURO DYNE 010012 CONNECTOR

Product Description

The DURO DYNE SMFN-100 (010012) is a flexible duct connector made for commercial use. It features a configuration of three inches of metal, six inches of fabric, and three inches of metal. This connector has a Grip-Loc seam that ensures a secure fit. It uses 24-gauge galvanized steel in accordance with ASTM A525 G60 standards and neoprene-coated woven fiberglass fabric. The product is ideal for heating, cooling, ventilation, and industrial applications, providing an airtight joint that helps isolate vibrations and noise.

• Constructed with 24-gauge galvanized steel meeting ASTM A525 G60 standards.
• Features a neoprene-coated woven fiberglass fabric.
• Suitable for heating, cooling, ventilation, and industrial applications.

Product Highlights

This duct connector ensures durability and flexibility in various applications.

Product Information

Standard Information

• Type: Flexible Duct Connector
• Size: 3 Inch Metal x 6 Inch Fabric x 3 Inch Metal

Technical Specifications

• Material Thickness: 24 Gauge
• Metal Material: ASTM A525 G60 Galvanized Steel
• Fabric Material: Neoprene coated woven fiberglass
• Applicable Standard: UL 214/R4462, NFPA 701/90A/B
• Seam: Grip Lock
• Temperature Rating: -40 to 200 Deg F
• Tensile Strength: 500 Pound Wrap, 450 Pound Fill
• Tear Strength: 12 Pound (Wrap/Fill)
