Duff Norton TMD02-1906-4 Electromechanical Linear Actuator 12 VDC 250 lb

Product Description

The Duff Norton TMD02-1906-4 is an electromechanical linear actuator designed for reliable performance with a lifting capacity of 250 lb. This actuator operates on 12 VDC, providing efficient power for various applications. Its compact design allows for easy installation in limited spaces.

• 250 lb capacity
• 4 inches travel length
• Double clevis end configuration

Product Highlights

The TMD02-1906-4 actuator is equipped with adjustable limit switches and allows for quiet operation thanks to its belt drive mechanism. It is suitable for use in industrial automation, robotics, and other applications requiring precise linear motion.

Product Information

Standard Information

• Brand: Duff Norton
• MPN: TMD02-1906-4

Technical Specifications

• Brake: Dynamic Braking
• Motor Voltage: 12 VDC
• Capacity @ Zero Travel: 250 lb
• Travel: 4 inches
• Temperature Range [Max]: 120 °F
• Width: 4.90 inches
• Limit Switches: Yes
• End Configuration: Double Clevis
• Lifting Speed: 24.0 inches/min
• Drive: Double Lead Screw
• Closed Height: 9 inches
• Depth: 3.200 inches
• Temperature Range [Min]: 25 °F
• Weight: 6.0 lb
