Dormakaba L8146R-26D-41 Mortise Combination Lever Lock 1 Pack Replacement L8146R-26D-41

Brand: DORMAKABA
SKU: L8146R-26D-41
Availability: In Stock

Ships same day if ordered by 12 pm
$710.86
$710.86
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Dormakaba L8146R-26D-41 is a mortise combination lever lock with mechanical pushbutton access that provides key override and lockout functions. Prepared for Sargent LFIC cores and supplied less core, the lock includes a 2-3/4" (70 mm) backset, 3/4" (19 mm) two-piece anti-friction latch, fixed ADA-compliant levers, and a vandal-resistant metal numeric keypad. It fits standard (86) mortise prep on 1-3/4" to 2-1/4" doors and uses a single access code programmable at the door.

  • Mortise pushbutton combination lock with key override and lockout; prepared for Sargent LFIC, core not included
  • 3/4" (19 mm) two-piece anti-friction latch, 2-3/4" (70 mm) backset; fits 1-3/4" to 2-1/4" door thickness
  • Cast front housing with unified trim plate, fixed ADA-compliant levers, and vandal-resistant solid metal pushbuttons

Product Highlights

Mechanical pushbutton mortise lock; Sargent LFIC prep; single access code; programmable at door

Product Information

Standard Information

  • Brand: DORMAKABA
  • Manufacturer Part Number: L8146R-26D-41
  • Country of Origin: Mexico
Technical Specifications
Brand
Dormakaba
Manufacturer Part Number
L8146R-26D-41
Product Type
Mortise combination lever lock (mechanical pushbutton)
Function
Combination lever lock — key override, passage, lockout
Cylinder Prep
Sargent LFIC prep
Core Included
Less core (core not included)
Key Override
Yes (prepared for removable LFIC/large format cores or interchangeable small format cores)
Lockout
Yes
Finish
Satin Chrome
Handing
Factory-handed (left hand listed on some configurations)
Backset
2-3/4" (70 mm)
Latch
3/4" (19 mm) two-piece anti-friction latch
Optional Deadbolt
1" (25 mm) deadbolt available on select models
Door Thickness
1-3/4" (44 mm) to 2-1/4" (57 mm)
Minimum Stile Recommended
5" (127 mm)
Door Preparation
Standard (86) mortise preparation; installs on wood or metal doors
Strike Plate
Approximately 4.00 x 1.25 x 0.25 inches (124 mm x 32 mm x 6 mm) mortise strike plate
Housing Construction
Cast front housing with unified trim plate
Levers
Fixed ADA-compliant levers
Keypad
Vandal-resistant solid metal numeric pushbuttons
Access Codes
Single access code
Programming
Programmable at the door via keypad
Fire Rating
3-hour UL/ULC fire rating for labeled doors (where applicable)
Certifications
ADA compliant
Material / Base
Brass or bronze base
Mounting Type
Mortise
Weight
9.8 lbs (3.7 kg)
