Product Description
The DORMAKABA E2031BLL-626-41 E-Plex 2000 Series provides exterior access via combination, while allowing free egress. This electronic pushbutton lock eliminates costs associated with issuing and managing keys and cards. It features up to 100 access codes and is easily programmed via the keypad or optional Microsoft Excel-based software.
- Electronic pushbutton lock eliminates problems and costs associated with issuing, controlling, and collecting keys and cards.
- Provides exterior access by PIN code, while allowing free egress.
- Heavy-duty commercial Grade 1 lockset
Product Highlights
This electronic lock is ideal for commercial applications, offering keyless entry, audit trail capabilities, and robust construction for enhanced security and convenience.
Product Information
Standard Information
-
Brand: DORMAKABA
-
Manufacturer Part Number: E2031BLL-626-41
Technical Specifications
-
Brand: Dormakaba
-
Special Feature: Push Button
-
Lock Type: Cylindrical
-
Material: Alloy Steel
-
Recommended Uses For Product: controlled access to commercial doors
-
Controller Type: Push Button
-
Control Method: Push Button
-
Smart Home Compatibility: Not Smart Home Compatible
-
Style Name: Modern
-
Shape: Round
-
Material Type: Alloy Steel
-
Finish Types: Polished
-
Access Control: Electronic pushbutton lock
eliminates problems and costs associated with issuing, controlling, and collecting keys, and cards. Provides exterior access by PIN code, while allowing free egress.
-
Lockset Grade: Heavy-duty commercial Grade 1 lockset, solid cast exterior housing, solid cast levers, cylindrical drive wear tested for extensive use in indoor and outdoor applications
-
Fire Rating: UL 10C fire rated
-
Pushbuttons: Vandal-resistant, solid metal pushbuttons
-
Wiring: No Wires: Requires no wiring to or through the door
eliminates risk of damage from pinched wires that can result in costly callbacks
-
Number of Codes: 100
-
Handing: Reversible
-
Audit Trail: The most recent 1,000 events are recorded in memory, including the use of mechanical key override. Software is required to view Audit Events
-
Programming: Lock is easily programmed via keypad without removing lock from the door or with optional Microsoft Excel-based software
-
Key Override: Best and Equivalents (6 or 7-pin length); cylinder not included
-
Finishes: Satin Chrome 626 (26D) housings and levers, Satin Brass 606 (04) or Dark Bronze 744 (10B) housings and levers.
-
Lock Function: Pushbutton Keypad
-
Key Override Type: E2031B: Prepped for 6 or 7-pin SFIC
-
Usage: Heavy Duty
-
Backset: 2 3/4 in.
-
Latch: 1/2" throw - 1-1/8" x 2-1/4" face
-
Strike: Packaged standard with both ANSI A11.53 Strike and A115.2 ASA Strike
-
Power: Three AA Alkaline batteries provide up to 100,000 cycles
-
ADA Compliance: Meets ADA requirements - A117.1 Accessibility Code
-
Door Thickness: 1 3/8 in. to 2 1/2 in.
-
ANSI Rating: A156.25, Grade 1 (Best)
-
Battery Type: AA
-
BHMA Rating: Grade 1 (Best)
-
Keyway: Best IC
-
Lock Features: Audit Trail, Passage Mode
-
Solution: Electronic
-
Handle Type: Lever Handle Door Locks
-
Access Type: Key
-
Keypad - Digits: 4 to 8 Digits
-
Locking Device: Cylindrical Latch
-
Door Prep: Standard 2 1/8 in. Cross-Bore, Edge Bore: 1 in., Through-Bolt Hole(s)
-
Door Opening: Standard
-
Code Length: 4 to 8 Digits
-
Code Capacity: 100
-
Users: 100
-
Door Thickness Minimum: 1 3/8 in.
-
Door Thickness Maximum: 2 1/2 in.
-
Door Stile Width: Minimum 5 in.
-
Series: E-Plex 2000
-
Function: Keypad w/ Key Override
-
Lockset type: Cylindrical Lock
-
Locking Device Option: Cylindrical 1/2" (13 mm) throw latch, floating face plate 2-3/4" (70 mm) backset
-
Authority Levels: Five different levels allow who has access to specific lock functions, including: Service Codes
programmed for one-time access or come-and-go access for 1 to 24 hours
-
User Parameters: Code length
adjustable to accept 4 to 8 digits Anti-tamper lockout
adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds Re-lock time
adjustable from 2 to 20 seconds
-
Lock Power: Battery Powered - Batteries located in outside housing; offers quick and easy battery replacements (three AA Alkaline batteries provide up to 100,000 cycles); lock data is maintained if batteries fail.
-
Construction: Heavy-duty commercial Grade 1 lockset, solid cast exterior housing, solid cast levers, cylindrical drive wear tested for extensive use in indoor and outdoor applications
-
Numeric Keypad: Vandal resistant, solid metal pushbuttons
-
Latches: Cylindrical: 1/2" (13 mm) throw latch
-
Minimum Stile Required: 5" (127 mm)
-
Ease of Installation: No wiring to or through the door
no risk of pinched wires
-
Door Preparation: Cylindrical and Exit Trim
ASA 161 (easily installs on door preparation with three additional through bore holes; wood or metal doors)
-
Accessibility Standard: Americans with Disabilities Act (ADA)
-
Environmental: Indoor/Outdoor approved; -31 F (-35 C) to 151 F (66 C); Windstorm approved/certified
-
Durability: ANSI/BHMA Grade 1 Certified (A156.25, A156.2, A156.13, A156.3)
