Donaldson P569638 Hydraulic Indicator Assembly 3 in

Product Description

The Donaldson P569638 Hydraulic Indicator Assembly is an essential component for hydraulic systems. This assembly features an overall length of three inches and is designed for effective actuation. It is built to meet the high standards set for hydraulic indicators.

• Three inches overall length
• Visual and electrical actuation style
• Compatible with HPK02, HPK03, HPK04, and HPK05 series

Product Highlights

This hydraulic indicator assembly is designed for reliable performance in hydraulic applications.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: 100176939

Technical Specifications

• Electrical Type: 115V AC / 28V DC, 5 AMP
• Thermal Lockout: Yes
• Indicator Actuation: 35 psid
• Seal Material: Viton
• Series: HPK02, HPK03, HPK04, HPK05
• Bypass Valve Setting LR: 34.81 psi, 2.4 bar
• Style: Visual, Electrical
• Bypass Valve: Yes
• Connector Style: Hirschmann
• Overall Length: 3 in, 76.2 mm
• Weight: 0.4 LB
• EAN or UPC: 742330197028
