Don-jo CW25810B Wrap Around Double Lock Oil Rubbed Bronze

Product Description

The DON-JO CW25810B is a classic wrap around plate designed for double lock combination locksets with two 2.125-inch holes. It accommodates a 5.5-inch center spacing, a 2.75-inch backset, and fits 1.75-inch doors. Finished in oil rubbed bronze, this wrap around reinforces the door face around the lockset cutouts, adding a layer of protection against forced entry and improving the finished appearance of the installation. Licensed locksmiths, door hardware installers, and general contractors install this hardware on residential and light commercial doors.

This wrap around plate is suited for interior and exterior door applications where a double lock combination lockset is specified. It is designed for standard 1.75-inch door thickness and works with the common 2.75-inch backset configuration found on most residential and light commercial cylindrical locksets. The oil rubbed bronze finish provides a consistent appearance when paired with matching door hardware on the same opening.

Key Features

• Accepts two 2.125-inch bore holes for double lock combination lockset configurations
• 5.5-inch center-to-center hole spacing matches standard double lock prep
• Compatible with 2.75-inch backset locksets
• Sized for 1.75-inch door thickness
• Oil rubbed bronze finish for a consistent architectural appearance
• Lightweight construction at 0.4 pounds for easy single-person installation

Compatibility

Designed as an OEM-style replacement or new-installation wrap around for double lock combination locksets with a 5.5-inch center, 2.75-inch backset, and 1.75-inch door thickness.

Installation Notes

Installation is typically performed by a licensed locksmith or qualified door hardware installer. Ensure the door prep matches the required 5.5-inch center and 2.75-inch backset before mounting. Remove the existing lockset before installing the wrap around plate, and confirm the bore hole diameters are 2.125 inches to ensure proper fit. Follow applicable building codes for door hardware reinforcement requirements on the project.
