Dixon Valve GL350 Standard Dry Gauge

Product Description

The Dixon Valve GL350 is a standard dry gauge suitable for pumps, hydraulic and pneumatic systems, compressors, and machine tools. This gauge uses a PowerFlex movement with a polyester segment to resist shock, vibration, and pulsation.

• Features a durable C-shaped bronze safety bourdon tube.
• Includes a corrosion-resistant ABS plastic case.
• Equipped with a polycarbonate crystal for protection.

Product Highlights

This gauge provides reliable pressure readings and can operate under extreme conditions.

Product Information

Standard Information

• Manufacturer Part Number: GL350
• Brand Name: Dixon

Technical Specifications

• Type: Standard Dry
• Connection Size: 1/4 inches
• Material: ABS Case
• Pressure Range: 0 to 600 psi
• Temperature Rating: -40 to 150 degrees Fahrenheit
• Standard Approvals: ASME B40.100 Grade B
• Accuracy: ± 3-2-3%
• Mounting Type: Lower Mount
• Dial Diameter: 2-1/2 inches
• Weight: 0.2400 lbs
