Dixon Valve D4M4-S DF-Series Pneumatic Male Threaded Plug

Product Description

The Dixon Valve D4M4-S is a DF-Series pneumatic male threaded plug made from durable materials. This product is suitable for use in pneumatic systems and adheres to multiple industry standards.

• Made with 303 stainless steel
• Features a 1/2 inch male NPTF thread
• Compatible with Foster, Parker, and Hansen series couplings

Product Highlights

The D4M4-S provides reliable performance in various pneumatic applications. Its robust design ensures long-lasting use.

Product Information

Standard Information

• Brand: Dixon Valve
• MPN: D4M4-S

Technical Specifications

• Series: DF-Series
• Body Size: 1/2 inch
• Thread Size: 1/2 inch
• Thread: NPTF
• Material: 303 Stainless Steel
• Pressure Rating: 500 psi
• Temperature Range: -40°F to +250°F
• Length: 2.34 inches
• Hex Size: 7/8 inches
• Maximum OD: 1.01 inches
• Weight: 0.16 lb
• Compatibility: Interchanges with Foster 3, 4, 5, and 6 Series; Parker 30-Series Automatic and 20-Series Manual Interchange; Hansen 3000, 4000, 5000, 6000 and Hansen 1000, 400, 500
