Dixon Valve & Coupling GL130 Dry Pressure Gauge

Product Description

The Dixon Valve & Coupling GL130 is a dry pressure gauge designed for durability and reliability in various applications. It is built to handle the demands of hydraulic and pneumatic systems, compressors, and machine tools. This gauge helps ensure accurate pressure readings in environments where corrosion may be a concern.

• Gauge Pressure Range: 0 to 160 psi
• Durable ABS plastic case and design
• Lower mount style for easy installation

Product Highlights

The GL130 is known for its PowerFlex movement with a polyester segment, which protects against shock, vibration, and pulsation, making it suitable for challenging conditions.

Product Information

Standard Information

• Brand: Dixon Valve & Coupling
• Part Number: 101892959

Technical Specifications

• Gauge Pressure Range: 0 to 160 psi
• Pressure Range (Max): 160 psi
• Temperature Range (Max): 150 °F
• Material: ABS Plastic
• Pressure Range (Min): 0 psi
• Mounting Style: Lower Mount
• Case Material: ABS Plastic
• Face Diameter: 2 inches
• NPT Male: 1/4 inches
• Gauge Function: Pressure Gauge
• Gauge Type: Dry
• Temperature Range (Min): -40 °F
• Weight: 0.17 LB
