Diversitech qswi5002 Swivel Ceiling Mount 400 Lb Unit Heater

Product Description

The DIVERSITECH qswi5002 is a heavy-duty swivel ceiling mount bracket designed for flush installation of large ceiling-mounted unit heaters, concealed ducted air handlers, and branch controllers. Built from powder-coated steel, it carries a rated load capacity of 400 pounds and ships with a 52-inch I-style bracket for flush ceiling attachment. The swivel mechanism allows 360-degree rotation so technicians can dial in the correct airflow direction before hard piping the unit. Adjustable design accommodates multiple ceiling mounting configurations across a range of job sites.

This mount is used in commercial and industrial settings where large unit heaters or ceiling-mounted air handlers require secure, adjustable overhead support. The flush ceiling mount profile keeps the installed unit close to the deck, which is preferred in low-clearance spaces. The 52-inch I bracket spans wider structural bays and distributes load across mounting points. HVAC technicians and mechanical contractors install this bracket as part of the initial equipment hang before refrigerant or gas piping begins.

Key Features

• 400-pound rated load capacity supports large unit heaters and air handlers
• 360-degree swivel rotation allows airflow direction adjustment before hard piping
• 52-inch I-style bracket suits flush ceiling mount applications
• Powder-coated steel construction for durability in mechanical spaces
• Adjustable design accommodates varied ceiling mounting configurations
• Compatible with both unit heaters and concealed branch controllers

Compatibility

Designed for use with large ceiling-mounted unit heaters, concealed ducted air handlers, and branch controllers requiring a flush ceiling mount with an I-style bracket configuration.

Installation Notes

Installation is performed by licensed HVAC technicians or mechanical contractors. De-energize all electrical circuits and shut off gas supply to the unit before beginning any overhead work. Verify that the ceiling structure can support the combined weight of the bracket and the hanging unit before fastening. Complete the bracket installation and set the swivel angle before hard piping refrigerant lines, gas piping, or electrical conduit to the unit.

Technical Specifications

• Load Capacity: 400 pounds
• Bracket Length: 52 inches
• Bracket Style: I-style
• Mount Type: Flat Ceiling Flush Mount
• Material: Powder Coated Steel
• Color: Tan
• Adjustable: Yes
• Application: Unit Heater

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: qswi5002
