Diversitech qswi3001 Quick Swivel Ceiling Mount Hanger 200 Lb

Product Description

The DIVERSITECH qswi3001 is a quick-swivel flush ceiling mount hanger designed for suspending concealed ducted air handlers and branch circuit controllers from flat ceilings. The assembly includes a 36-inch spreader bar in an H-bracket configuration that distributes load across the mounting surface. Constructed from powder-coated steel, it carries a rated load capacity of 200 pounds. The swivel mechanism allows full 360-degree rotation so the unit can be oriented in any direction before hard piping is completed. Licensed HVAC technicians and mechanical contractors are the primary installers of this hardware.

This hanger is suited for light commercial and residential ceiling applications where concealed ducted air handlers or branch circuit controllers require secure overhead support. The flat ceiling mount profile keeps the installation tight to the ceiling plane. The adjustable design accommodates various unit sizes and installation geometries, making it a practical choice for new construction and replacement work where fast, repeatable positioning is a priority.

Key Features

• 360-degree swivel rotation allows directional adjustment before final hard-pipe connections are made
• 36-inch H-bracket spreader bar distributes load across a wide ceiling footprint
• 200-pound rated load capacity supports standard air handlers and branch controllers
• Powder-coated steel construction provides corrosion resistance in mechanical spaces
• Adjustable design accommodates a range of unit sizes and ceiling conditions
• Flat ceiling mount profile for clean, flush installation

Compatibility

Designed for use with ceiling-mounted concealed ducted air handlers and branch circuit controllers requiring a flat ceiling suspension point with an H-bracket spreader configuration.

Installation Notes

Installation is typically performed by a licensed HVAC technician or mechanical contractor. De-energize all associated electrical circuits and isolate refrigerant lines before mounting the air handler or branch controller to this hanger. Confirm that the structural ceiling surface can support the rated load of the hanger plus the full weight of the suspended unit before fastening. Complete all swivel adjustments and set final unit orientation before making hard-pipe refrigerant or fluid connections.

Technical Specifications

• Load Capacity: 200 pounds
• Spreader Bar Length: 36 inches
• Mount Type: Flat Ceiling
• Material: Powder Coated Steel
• Color: Tan
• Adjustable: Yes
• Application: Air Handler, Branch Controller

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: qswi3001
