DIVERSITECH FF8.5HBK1 Hermetic Reciprocating Compressor 1/4 HP

Product Description

The DIVERSITECH FF8.5HBK1 is a hermetic reciprocating compressor ideal for refrigeration applications. This model operates using R-134a refrigerant and is compatible with a 115 VAC single-phase power supply at 60 Hz. It is effective in low, medium, and high back pressure settings.

• Hermetic reciprocating compressor design.
• Utilizes R-134a refrigerant and polyolester (POE) oil.
• Includes a sweat or braze suction line fitting.

Product Highlights

The compressor features a normal starting torque and is designed for a variety of applications in both residential and commercial refrigeration.

Product Information

Standard Information

• Manufacturer Part Number: FF8.5HBK1
• Country of Origin: BRA

Technical Specifications

• Compressor Type: Reciprocating
• Motor HP: 1/4 HP
• Voltage: 115 VAC
• Phase: Single
• Cycle/Hertz: 60 Hz
• Oil Type: Polyolester (POE)
• Suction Line Size (OD): 5/16 inches
• Discharge Connection Size (OD): 1/4 inches
• BTU Output: 3,135
• Amps: 2.88
• Compressor Housing: Hermetic
• Evaporating Temperature: -40°F to 10°F (-40°C to -12.22°C)
• Mounting Dimensions: 6.69 x 2.76 x 7.91 inches
• Suction Line Fitting Type: Sweat or Braze
• Foot Mount: Standard Mount: 4 x 6.69 inches
• BTU LT @ -10°F: 740
• BTU MT @ 20°F: 1745
• BTU HT @ 45°F: 3135
