Diversitech DDS-60 Fusible Disconnect Switch 60A (Each) DDS60

Product Description

The Diversitech DDS-60 is a 60 Amp fusible pull-out disconnect switch designed for HVAC and electrical installations. The DDS-60 features a pull-out handle with fuses housed in the handle and indicator lights to identify blown fuses. It includes a reversible side-opening door that opens more than 180 degrees for full access and IP54 protection for dust and water resistance, with line, load, and ground terminals aligned for straightforward wiring.

• 60 A fused pull-out disconnect with fuses installed in the pull-out handle and indicator lights for blown-fuse identification
• Reversible side-opening door opens >180 degrees and provides a full dead front; line, load, and ground terminals aligned for straight-line wiring
• IP54 dust and water protection; suitable for HVAC/Air conditioner disconnect applications; UL listed (IRF9) and U.S. Patent 6,630,637

Product Highlights

60A fusible pull-out disconnect with fuses in handle, blown-fuse indicator lights, reversible side door, and IP54 protection

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: DDS-60
• Country of Origin: China

Technical Specifications

• Brand: Diversitech
• Manufacturer Part Number: DDS-60
• Model: DDS60
• Product Type: Fusible pull-out disconnect switch
• Current Rating: 60 A
• Voltage Rating: 240 VAC
• Horsepower: 10 hp
• Disconnect Mechanism: Pull-out handle
• Number Of Fuses: 2
• Fuse Feature: Fuses in pull-out handle; indicator lights for blown fuses
• Door: Side-opening; reversible; opens >180 degrees; full dead front
• Terminal Arrangement: Line, load, and ground terminals aligned for straight-line wiring
• Enclosure Protection Rating: IP54
• UL Listed: IRF9
• Patent: U.S. Patent 6,630,637
• Application: HVAC / Air conditioner disconnect
• Material: Metal / heavy gauge steel
• Package Dimensions: 9.21 x 5.20 x 3.03 inches
• Knockouts: Rear entry knockouts; accommodate 1/2", 3/4" and 1"
