Product Description
The Diversitech CP-22LP-230 is a condensate pump with a 22-foot lift capacity, designed for removing condensate from HVAC and refrigeration systems. It operates on a 230-volt power supply. The pump is constructed with durable materials and features a compact design for easy installation in tight spaces.
- Features vibration dampening feet and motor mounts
- Includes four inlet holes, LED display, float switch and check valve
- Suitable for use with condensate up to 160°F
Product Highlights
This Diversitech condensate pump is ideal for air conditioners, dehumidifiers, and refrigeration units in both residential and commercial settings.
Product Information
Standard Information
-
Brand: DIVERSITECH
-
Manufacturer Part Number: CP-22LP-230
-
Country of Origin: Vietnam
Technical Specifications
-
Voltage: 230V
-
Power Source: Ac/dc
-
Item Model Number: CP-22LP-230
-
Part Number: CP-22LP-230
-
Model / MPN: CP-22LP-230
-
Manufacturer: Diversitech
-
Brand: DiversiTech
-
Flow Rate: 1.6 GPM
-
Shutoff Head (ft): 22'
-
Hertz: 60
-
Capacity: 1/3 Gallon
-
Lift: 22' of Lift
-
Includes: Safety Switch
-
Horse Power: 1/30
-
Max Temp (F): 160°F
-
Max Flow (GPH): 96
-
Number of Inlets: 4
-
Amps: 1
-
Discharge Line (In.): 3/8
-
High Level Switch: Yes
-
Input Type: NEMA 6-15 Plug
-
Max Condensate Temp. (Degrees): 160°F
-
Max Lift Height (Ft.): 22
-
Self-Cleaning: No
-
Tank Capacity (Gal.): 1/3
-
Variable Speed and Lift: No
-
Ducted or Ductless: Ducted
-
Overall Dimensions: 11.8 Inch Length x 5.9 Inch Width x 6.7 Inch Height
-
Reservoir Capacity: 3/8 Gallon
-
Warranty: 2 Year
-
Input Supply Rating: 230 Volt AC 60 Hertz 1 Amp
-
Temperature Rating: 160 Deg F
-
Inclusions/Features: (4) Inlet Hole, Clear Indicator Display, Float Switch and Check Valve, Instruction Booklet, Metal Hang Tab, Plug Protector, 4 Foot Remote Shut-Off Lead with Insulated Terminal, (3) Polyethylene Inlet Cover
-
Application: High Efficiency Furnace, Humidifier
-
Applicable Standard: UL, NEC
-
Inlet Height from Base: 4.4 Inch
-
Line Voltage (60Hz): 240V
-
Tubing Connection Size: 1/4"
-
Height: 5 in
-
Length: 12 in
-
Width: 6 in
