Diversitech 3GR7555 Motor Run Capacitor 370 VAC (55+7.5 uF / Pack of 1) 0278-5158

Product Description

The DiversiTech 3GR7555 is a dual motor run capacitor rated 370 VAC with capacitance 55 + 7.5 uF in a round can design. It is oil filled (non-PCB), rated for 50/60 Hz operation with ±5% tolerance, and has 1/4" quick connect terminals. The capacitor meets UL-810, CSA22.2 No190, and IEC60252 standards, has a permissible temperature range of -40°C to +70°C, and is specified for continuous motor run applications.

• Dual capacitance 55 + 7.5 uF, 370 VAC; rated frequency 50/60 Hz; capacitance tolerance ±5%
• Oil filled, non-PCB construction with 1/4" quick connect terminals; permissible temperature -40°C to +70°C
• Meets UL-810, CSA22.2 No190, IEC60252; withstand voltage tests and 10,000 AFC safety requirement; max permissible voltage 110% and current 130% of rated

Product Highlights

Dual 55+7.5 uF run capacitor, 370 VAC, oil filled non-PCB, 1/4" quick connect terminals, UL/CSA/IEC compliant.

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: 3GR7555
• Country of Origin: Mexico

Technical Specifications

• Brand: DiversiTech
• MPN: 3GR7555
• Manufacturer Part Number: 0278-5158
• Voltage Rating: 370 VAC
• Capacitance: 55 + 7.5 uF
• Capacitance Tolerance: ±5%
• Rated Frequency: 50/60 Hz
• Shape: Round (cylindrical can)
• Height: 4.33 Inches
• Diameter: 2.48 Inches
• Temperature Range: -40°C to +70°C
• Construction: Oil filled; non-PCB
• Terminal Type: 1/4" quick connect
• Standards: UL-810; CSA22.2 No190; IEC60252
• Operating Life: Guaranteed 10,000 hours; 94% life at 60,000 hours
• AFC Safety: Meets 10,000 AFC requirement per UL-810
• Withstanding Voltage (terminals): Rated voltage × 1.75, 10 sec
• Withstanding Voltage (terminals to case): Rated voltage × 2 + 1000 V, 60 sec
• Maximum Permissible Voltage: 110% of rated voltage
• Maximum Permissible Current: 130% of rated current
• Material: Metal housing (can)
• Application: Motor run applications; HVAC/refrigeration (furnace blowers, fan motors, compressors)
• Country of Manufacture: Mexico
• UPC: 095247071685
