Diversitech 3GR1035 Motor Run Capacitor 370 VAC (Pack 1) 0281-5719

Product Description

The DiversiTech 3GR1035 is a motor run capacitor providing dual capacitance of 35+10 uF at 370 VAC for HVAC motor applications. It is oil filled, non-PCB, and rated for 50/60 Hz operation with a capacitance tolerance of ±5% and an operating temperature range of -40°C to +70°C. The unit features 1/4 in quick connect terminals, UL-810/CSA/IEC compliance, and life ratings specified for continuous heavy-duty use in blower and fan motors.

• Dual capacitance 35+10 uF at 370 VAC; rated frequency 50/60 Hz; capacitance tolerance ±5%
• Oil-filled, non-PCB construction with 1/4 in quick connect terminals; operating temperature -40°C to +70°C
• Meets UL-810, CSA22.2 No190, IEC60252 and cRUus standards; guaranteed 10,000 hours life, 94% life at 60,000 hours

Product Highlights

Dual 35+10 uF motor run capacitor, 370 VAC, oil-filled non-PCB construction, 1/4 in quick connect terminals, UL/CSA/IEC certified

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: 3GR1035
• Country of Origin: US

Technical Specifications

• Brand: DiversiTech
• MPN: 3GR1035
• Part Number: 0281-5719
• UPC: 095247091874
• Type: HVAC motor run capacitor
• Shape: Round
• Capacitance: 35+10 uF
• Voltage Rating: 370 VAC
• Rated Frequency: 50/60 Hz
• Capacitance Tolerance: ±5%
• Operating Temperature Range: -40°C to +70°C
• Operating Life: Guaranteed 10,000 hours; 94% life at 60,000 hours
• Standards: UL-810; CSA22.2 No190; IEC60252; cRUus
• Construction: Oil filled; non-PCB; metal enclosure
• Terminal Type: 1/4 in quick connect
• Withstanding Voltage Between Terminals: Rated voltage × 1.75 (10 sec)
• Withstanding Voltage Between Terminals and Case: Rated voltage × 2 + 1000 VAC (60 sec)
• Maximum Permissible Voltage: 110% of rated voltage
• Maximum Permissible Current: 130% of rated current
• Dimensions (L x W x H): 2.17 x 2.28 x 3.94 in
• Weight: 0.56 Pounds
• Country of Origin: United States
• Datasheet: https://media.cityelectricsupply.com/media/diversitech/3gr1035/documents/diversite_datasheet_1050055.pdf
• Packaging: Individually packaged; pack of 1 unit
