Diversitech 25-90382 General Purpose Relay 120VAC

Product Description

The Diversitech 25-90382 general purpose relay is designed for cooling, heating, or general purpose switching equipment operating heavier loads. This heavy duty relay allows a small electric current to turn on or off a larger electric current. It features a totally enclosed compact design for quiet and reliable operation.

• Designed for cooling, heating or general purpose switching equipment operating heavier loads
• Totally enclosed compact design
• Universal mounting bracket

Product Highlights

This Diversitech relay features a universal mounting bracket and quick-connect terminals for easy installation. It is suitable for various applications requiring reliable switching.

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: 25-90382

Technical Specifications

• Amperage Rating: 18 A
• Voltage Rating: 120V
• Coil Voltage: 120 V
• Frequency Rating: 50, 60 Hz
• Mounting Type: Universal
• Standard: cURus Listed
• Terminal Size: 1/4" Quick-Connects
• Type: Heavy Duty
• Temperature Range: -4°F - 104°F (-20°C - 40°C)
• Mechanical Life: 1,000,000 operations
• Electrical Life: 100,000 operations (@ 25amp 277VAC Res)
• Operate Time: 25ms at nominal coil voltage
• Release Time: 25ms at nominal coil voltage
• Dielectric Strength: 2500 Vrms coil to contact
• Coil Frequency: 50/60 Hz
• Coil Insulation: Class A (105°C/221°F)
• Coil Duty Cycle: Continous
• Contact Material: Silver Cadmium Oxide
