Diode LED DI-CV-24V200W 24V Hardwired Constant Voltage LED Driver

Product Description

Diode LED DI-CV-24V200W is a constant voltage LED driver designed for low voltage applications. This hardwired driver supports a variety of LED tape lights and fixtures, making it ideal for indoor and dry locations. Its robust design ensures stability and efficiency while powering your LED systems.

• Short circuit, over current, over voltage, and over temperature protections.
• Compatible with DI-0940 Meanwell junction box and DI-1733 mounting brackets.
• Provides 200 watts of power with adjustable voltage settings.

Product Highlights

This driver operates with a wide input voltage from one hundred to two hundred forty volts AC and outputs twenty-four volts DC. The built-in cooling fan and high efficiency make it reliable for long-term use.

Product Information

Standard Information

• Brand: Diode LED
• Part Number: P8113

Technical Specifications

• Amperage Rating: 3.5/1.7 A
• Application: For low voltage LED tape light and fixtures, indoor and dry locations
• Height: 2.5 inches
• Input Voltage: 100 to 240 VAC
• Length: 9.77 inches
• Material: Aluminum
• Mfg Standards/Approvals: CE Marked, cULus 60950-1
• Output Voltage: 24 VDC
• Package Weight: 1.87 lb
• Power Factor: >0.97/>0.93
• Power Rating: 200 W
• Temperature Rating: 14 to 140 deg F
• Type: Hardwired Constant Voltage
• Width: 4.14 inches
