Dexter Commercial DB2000SCT613SFIC Grade 2 Deadbolt Sfic

Product Description

The DEXTER COMMERCIAL DB2000SCT613SFIC is a Grade 2 single cylinder turn deadbolt finished in oil rubbed dark bronze (finish 613), designed for commercial door applications where a cost-effective, code-appropriate locking solution is required. The deadbolt accommodates Small Format Interchangeable Core (SFIC) cylinders, accepting both 6-pin and 7-pin cores to support master-key and large-key-system deployments common in commercial facilities. The unit ships with a universal square corner latch and a lipless strike, covering a standard door prep without additional hardware. Locksmiths, door hardware installers, and commercial general contractors are the typical installing trades.

This deadbolt is suited for interior and exterior commercial doors in cost-constrained projects such as office buildings, multi-tenant facilities, retail spaces, and institutional applications. The SFIC door range of 1.625 inches to 2.75 inches accommodates heavier commercial door constructions, while the standard cylinder door range of 1.375 inches to 1.875 inches covers conventional hollow-metal and wood door frames. The included 2.375 inch to 2.75 inch universal square corner latch provides flexible backset adjustment without swapping components.

Key Features

• Grade 2 commercial deadbolt rated for common door applications in cost-constrained environments
• SFIC-ready cylinder housing accepts 6-pin and 7-pin small format interchangeable cores
• Standard cylinder door range: 1.375 inches to 1.875 inches; SFIC door range: 1.625 inches to 2.75 inches
• Includes universal square corner latch (2.375 inches to 2.75 inches backset) and 1.125 inch x 2.75 inch square corner lipless strike
• Oil rubbed dark bronze finish (613) suits standard commercial door hardware finish schedules
• Aluminum and stainless steel construction

Compatibility

Accommodates SFIC cores accepting 6-pin and 7-pin configurations. Schlage C keyway cylinders are 6-pin, keyed to keyway 6, keyed different. Designed as an OEM-style replacement or new-installation deadbolt for Grade 2 commercial door applications using standard ANSI prep dimensions.

Installation Notes

Installation should be performed by a licensed locksmith or qualified door hardware installer familiar with ANSI/BHMA Grade 2 hardware requirements. Power to any electrified door hardware in the immediate assembly should be de-energized before beginning work. Verify door thickness and backset before installation to confirm latch and strike fitment. SFIC cores must be ordered separately and should be inserted and tested after the deadbolt body is fully secured to the door.
