Dewalt DCD801B 20V Max Xr Brushless Drill Driver

Product Description

The DEWALT DCD801B is a brushless cordless drill/driver built for professional-grade performance on demanding jobsite applications. Powered by the 20V MAX XR platform, this tool delivers variable speed operation with two speed settings: 0-650 RPM and 0-2,000 RPM via a high-speed transmission and variable speed trigger. The 1/2 inch metal ratcheting chuck provides secure bit retention across a wide range of fastening and drilling tasks. The integrated ANTI-ROTATION System monitors rotational motion and shuts the tool down if motion becomes excessive, giving tradespeople added control during high-torque applications. Battery and charger are sold separately.

The DCD801B is suited for residential and commercial construction, mechanical trades, and general jobsite work where a compact, high-output drill/driver is required. With up to 175 holes per charge on a compatible 20V MAX battery, it handles repetitive fastening tasks without interruption. The 3-position adjustable LED worklight with 70 lumens and auto-shutoff improves visibility in confined or low-light work areas. This tool is also TOOL CONNECT CHIP READY, compatible with the DEWALT Site Manager app for asset tracking and tool location when a DEWALT chip is installed separately.

Key Features

• Brushless motor with 2-speed transmission: 0-650 and 0-2,000 RPM
• ANTI-ROTATION System shuts tool down if excessive rotational motion is detected; red LED indicator confirms engagement
• 1/2 inch metal ratcheting chuck for secure bit retention
• 3-position LED worklight with 70 lumens and auto-shutoff
• TOOL CONNECT CHIP READY for use with DEWALT Site Manager app (chip sold separately)
• Part of the 20V MAX XR platform; battery and charger sold separately

Compatibility

Compatible with all DEWALT 20V MAX batteries. Designed for use within the 20V MAX XR cordless tool ecosystem. TOOL CONNECT functionality requires a separately purchased DEWALT chip and the DEWALT Site Manager app.

Installation Notes

Installation and use of this tool should follow applicable safety standards and manufacturer guidelines. Always ensure the battery is removed before changing bits or performing adjustments to the chuck. The ANTI-ROTATION System is an assistive safety feature and does not replace proper two-handed grip technique on high-torque applications. Refer to the included operator manual for full operating procedures.

Technical Specifications

• Voltage: 20V MAX
• Speed Settings: 2 (0-650 RPM / 0-2,000 RPM)
• Chuck Size: 1/2 inch metal ratcheting
• LED Worklight: 3-position, 70 lumens, auto-shutoff
• Max Holes Per Charge: 175
• Length: 9 inches
• Width: 3.5 inches
• Height: 7.1 inches
• Weight: 3.2 pounds
• UPC: 028877366324

Standard Information

• Brand: DEWALT
• Manufacturer Part Number: DCD801B
