Dewalt 05175S-PWR Lok-bolt Anchor 1/4 X 2-1/4 in Acorn Head

Product Description

The DEWALT 05175S-PWR is a 1/4 x 2-1/4 inch Lok-Bolt wedge anchor with an acorn head configuration. Lok-Bolt anchors are designed to provide secure, load-bearing fastening into concrete and masonry substrates. The acorn head style covers the exposed bolt end after installation, delivering a finished appearance where aesthetics matter alongside structural integrity. This type of anchor is a standard fastener used by commercial and residential contractors, electricians, plumbers, and HVAC technicians when securing equipment, brackets, and structural components to concrete floors, walls, and ceilings.

The 05175S-PWR is suited for light to medium-duty anchoring applications in poured concrete and concrete masonry unit substrates. Typical installations include securing equipment pads, pipe hangers, conduit supports, duct supports, and mechanical equipment bases to concrete surfaces. The 1/4 inch diameter and 2-1/4 inch length make it appropriate for applications requiring a low-profile fastener with reliable holding strength in standard concrete conditions.

Key Features

• 1/4 x 2-1/4 inch wedge anchor format for concrete and masonry fastening
• Acorn head design covers the exposed threaded end for a finished appearance
• Lok-Bolt wedge mechanism expands on installation for positive mechanical hold
• Suitable for securing mechanical, electrical, and plumbing support hardware to concrete

Compatibility

Designed as a standard 1/4 inch diameter wedge anchor for use in poured concrete and concrete masonry unit applications where a 1/4 inch setting tool or hammer drill with matching bit is required.

Installation Notes

Installation is typically performed by licensed mechanical, electrical, or plumbing contractors using a hammer drill with a 1/4 inch carbide-tipped masonry bit. Drill hole depth must meet or exceed the minimum embedment requirement for the anchor length being used. Blow or vacuum debris from the hole before setting the anchor. Follow applicable building codes and fastener manufacturer load tables for minimum edge distance, spacing, and embedment to ensure rated holding values.

Technical Specifications

• Diameter: 1/4 inch
• Length: 2-1/4 inches
• Head Style: Acorn
• Anchor Type: Lok-Bolt Wedge Anchor
• UPC: 07535277744

Standard Information

• Brand: DEWALT
• Manufacturer Part Number: 05175S-PWR
